- 2 -
Copyright ©2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. Specification
Note:
1. All data are based on the following conditions:
- Cooling Temperature : Indoor 27°C(80.6°F) DB / 19°C(66.2°F) WB
Outdoor 35°C(95°F) DB / 24°C(75.2°F) WB
- Heating Temperature : Indoor 20°C(68°F) DB / 15°C(59°F) WB
Outdoor 7°C(44.6°F) DB / 6°C(42.8°F) WB
- Piping Length : Interconnected Pipe Length = 5m
- Difference Limit of Elevation (Outdoor ~ Indoor Unit) is Zero.
2. Wiring cable size must comply with the applicable local and national
code.
3. Due to our policy of innovation some specifications may be changed
without notification.
4. Sound Level Values are measured at Anechoic chamber.
Therefore, these values can be increased(maximum 3dB(A)) owing to
ambient conditions during opration.
Outdoor unit
A7UW40GFA0
[FM40AH UO2]
Testing Combination MS09AQ NB0 x 5EA
Capacity
Cooling
Min.~Rated~Max. kW 2.8 ~ 11.2 ~ 13.5
Min.~Rated~Max. Btu/h 9,600 ~ 38,200 ~ 46,000
Heating
Min.~Rated~Max. kW 3.1 ~ 12.5 ~ 15.0
Min.~Rated~Max. Btu/h 10,560 ~ 42,700 ~ 51,200
Power Input
Cooling Min.~Rated~Max. kW 0.78 ~ 2.73 ~ 4.15
Heating Min.~Rated~Max. kW 0.82 ~ 2.81 ~ 4.45
EER / COP W / W 4.10 / 4.45
Energy Efficiency Class (Rated) Cooling / Heating - A / A
SEER / SCOP Wh / Wh 5.60 / 3.81
Energy Efficiency Class (Seasonal)
Cooling / Heating - A+ / A
P-design Cooling / Heating (@-10°C) kW 11.2 / 11.8
Power Supply V , Ø , Hz 220-240 / 1 / 50
Running Current
Cooling Min.~Rated~Max. A 3.5 ~ 12.1 ~ 18.4
Heating Min.~Rated~Max. A 3.6 ~ 12.5 ~ 19.7
Starting Current
Cooling Max. A -
Heating Max. A -
Wiring Connections
Power Supply Cable (included Earth) No. x mm
2
(AWG) 3C x 2.5 (18)
Power and Communication Cable (included Earth)
Outdoor ~ BD unit No. x mm
2
(AWG) 4C x 1.25 (16)
Combination
Sum of Indoor Units Capacity kBtu/h 52
Number of Indoor Units EA 7
Number of BD Units EA 2
Casing Color - Warm Gray
Dimensions
W x H x D mm 950 × 1,170 × 330
W x H x D inch 37-13/32 x 46-1/16 x 13
Net Weight kg (lbs) 82(180.8)
Compressor
Type - Twin Rotary
Model Model x No. GPT442MBA x 1
Motor type - BLDC
Motor Output W x No. 4,000 (at 60Hz) x 1
Refrigerant
Type - R410A
Precharged Amount g (oz) 3,800(134.0)
Chargeless-Pipe Length
Main Pipe m (ft) 5(16.4)
Branch Pipe m (ft) 35(114.8)
Additional Charging Volume
Main Pipe g/m (oz/ft) 20(0.22)
Branch Pipe g/m (oz/ft) 50(0.54)
Control - Electronic Expansion Valve
Refrigerant Oil
Type - FVC68D
Charged volume cc x No. 1,300 x 1
Heat Exchanger
#1_(Row x Column x Fins per inch) x No. - (2 x 32 x 14) x1
#2_(Row x Column x Fins per inch) x No. - (2 x 22 x 14) x 1
Fan
Type - Propeller
Air Flow Rate m
3
/min x No. 45 x 2
Fan Motor
Type - BLDC
Output W x No. 85.4 x 2
Sound Pressure Level
Cooling Rated dB(A) 53
Heating Rated dB(A) 55
Sound Power Level Cooling Rated dB(A) 67
Piping Connections
Liquid Outer Dia. mm(inch) x No. Ø 9.52 (3/8) * 1EA
Gas Outer Dia. mm(inch) x No. Ø 19.05 (3/4) * 1EA
Piping Length
Total Piping Max. m (ft) 100 (328.1)
Main Piping Max. m (ft) 50 (164.0)
Total Branch Piping Max. m (ft) 50 (164.0)
Each Branch Piping Max. m (ft) 15 (49.2)
Maximum Height Difference
Outdoor Unit ~ Indoor Unit Max. m (ft) 30 (98.4)
Indoor Unit ~ Indoor Unit Max. m (ft) 15 (49.2)
Operation Range
(Outdoor Temperature)
Cooling Min. ~ Max. ℃ DB (℉ DB) -10 (14.0) ~ 48 (118.4)
Heating Min. ~ Max. ℃ WB (℉ WB) -18 (-0.4) ~ 18 (64.4)
