42
EN
only for the purpose described in this
manual. The manufacturer can’t be
considered responsible for possible
damage caused by improper, wrong,
or unreasonable uses.
WARNING
10. Before using the machine read
carefully the instruction manual
or, at least, the safety and setting
instructions.
11. This appliance is not suitable for
use by children or persons with
reduced physical, sensory or mental
capabilities, or by persons with a lack
of experience or knowledge, unless
supervised or given instructions.
12. The maximum and minimum storage
temperatures must fall within a range
of [-5, +50]°C.
13. The operating temperature must be
within the range of [+5, +35]°C.
14. At the end of installation, the device
is switched on and taken to rated
operating conditions, leaving it
in a state in which it is “ready for
operation”.
ȗ The device is then switched o and
the whole hydraulic circuit is bled
of the first lot of water in order to
remove any initial impurities.
ȗ The device is then refilled and taken
to rated operating conditions.
ȗ Aer reaching the “ready for
operation” condition, the following
dispensing operations are carried
out:
º 100% of the coee circuit through
the coee dispenser (in case of
several dispensers, this is divided
equally);
º 100% of the hot water circuit
through the water dispenser (in
case of several dispensers, this is
divided equally);
º opening of each steam outlet for 1
minute.
ȗ At the end of installation, it is good
practice to draw up a report of the
operations.
15. The use of any electrical device
must comply with fundamental
regulations. In particular:
ȗ do not touch the machine with wet
hands or feet;
ȗ do not use the machine barefoot;
ȗ do not use extensions in places used
as bath or shower;
ȗ do not pull the supply cable to
disconnect the machine from the
power mains;
ȗ do not leave the machine exposed to
atmospheric agents (rain, sun, etc.);
ȗ do not allow the machine to be used
by children or by non-authorised
personnel that haven’t read and
understood this manual.
ȗ During installation, equip the power
mains with a disconnector switch to
cut o each phase.
16. Before carrying out any maintenance
operation, the authorized technician
has to unplug the socket aer having
switched o the machine.
17. For cleaning, bring the machine to
state “O”, that is to say “machine
switched o and socket unplugged”
and follow only instructions in the
present manual.
18. In case of breakdown or wrong
functioning of the machine, switch
it o. Any intervention is strictly
forbidden. Contact exclusively
professionally authorized personnel.
The possible repair of the products will
have to be made by the manufacturer
only or by an authorized service using
exclusively original spare parts. Non-
compliance with the above stated can
compromise the safety of the machine.
