Before setting up the monitor, ensure that the power to the monitor, the computer
system, and other attached devices is turned off.
Positioning your display
1.Adjust the position of the panel in various ways for maximum comfort.
Tilt Range: 10˚~30˚
Ergonomic
It is recommended that in order to maintain an ergonomic and comfortable viewing
position, the backward tilt angle of the monitor should exceed 10 degrees.
