FHIABA S7490HST6 [3/26] 39 0434 420 160
![FHIABA S7490HST6 [3/26] 39 0434 420 160](/views2/2005529/page3/bg3.png)
29
2-3
2.1
2.2
2.3
3.1
www.fhiaba.com ∙ info@fhiaba.com ∙ Tel +39 (0)434 420160 ∙ Fax +39 (0)434 420161
EN
Make sure that installation is performed correctly, adhering
to all directions in the specic installation manual provided
with the appliance.
Installation
Connection to the electrical power supply
The appliance is equipped with a Schuko type 16A plug
and must be connected to the electrical power supply
through a corresponding Schuko socket.
Do not use extension cords and/or multiple adapters for
the power supply connection.
Do not use extension cords and/or mul-
tiple adapters for the power supply con-
nection.
Installation
Connection to the water system
The models provided with Ice Maker require a connection
to the domestic water supply system. This can be executed
through the provided water hose with 3/4” threading.
The system pressure must be between 0.05 MPa and 0.5
MPa (between 0.5 Bar and 5 Bar).
Differents pressures can cause malfunctions or leaks in the
water system. The appliance should be supplied only with
drinkable water.
The appliance should be supplied only with
drinkable water.
Make sure that installation is performed correctly,
according to all of the directions in the specic in-
stallation manual provided with the appliance.
Do not attempt to use a locally sourced garden
hose threaded adapter or braided supply line. It
will strip the threads on the appliance water con-
nection solenoid.
Know your appliance
If energy is supplied through an alternative energy
power source (solar, geothermal, etc..) or if home
automation systems are installed, it is necessary to
install the Alternative Energy Kit to integrate the unit
into the power grid.
Congratulations for having purchased your new Fhiaba:
from now on you can use our innovative conservation sys-
tem, which will allow you to keep all of your food in the
best way possible.
This manual will answer most of your questions about the
product’s features. Should you require further information,
please check our website
www.fhiaba.com
or write us an e-mail at
care@fhiaba.com.
Before calling, write down the model type and serial
number which are available on the warranty certicate
and on the rating plate located on the bottom left-hand
corner of the appliance, behind the bottom drawer and
any messages which may have appeared on the display.
+39 0434 420 160
