34
3.7
3.8
123456798
ICE MAKER
ENTER
FRIDGE
FRIDGE
FREEZER
UNIT
1
1
1
Unit
2
Fridge
3
Menu
4
Up/down
Fridge
5
Display
6
Up/Down
Freezer
7
Enter
8
Ice maker
9
Alarm
FRIDGE
FREEZER
3
Display
www.fhiaba.com ∙ info@fhiaba.com ∙ Tel +39 (0)434 420160 ∙ Fax +39 (0)434 420161
Main control panel
Freezer control panel
Switches the appliance (all compartments) between ON and STAND BY
(press for three seconds).
Allows switching ON and OFF of only the refrigerator compartment
(press for three seconds).
Allows access to the appliance function menu
It shows the temperature of the refrigerator and freezer compartments,
the date and time, Menu functions and visual messages.
By selecting Up/Down the preset temperature and navigate through
the interactive menu.
Confirms activation or deactivation of the selections made in the
Menu.
Allows activating or deactivating the automatic ice production.
Blinks to signal user alerts such as door left open, also in combination
with a sound signal which can be deactivated by pressing the button.
Using the Up and Down buttons, it is possible to change the set temper-
ature of the refrigerator and navigate through the interactive menu.
Before starting
Shows the temperature of the Freezer compartment.
