CLEANER MAINTENANCE
Replacing The Dust Bag
If the bag check indicator is red please check and, if necessary, replace the bag.
1. Lift the bag door release latch [13] to open the cover, pull the bag holder [14] and pull the
bag collar to remove the bag [15].
2. Apply the peel and seal sticker, located on the bag collar, to the bag inlet. The full dust bag
should be disposed of correctly and carefully.
3. Fold a new bag as shown on the bag and t by inserting the collar into the bag holder.
4. Ret the bag holder and close the bag door.
Warning - The bag door will NOT close if the dust bag and/or the bag holder are not assembled
to the cleaner. Always ensure the bag and bag holder are present when closing the bag door.
Remember: The bag check indicator may also be red if an obstruction has occurred. In this case
refer to ‘Removing A Blockage From the System’.
Cleaning the Filters
To maintain optimum performance of your cleaner, please wash the lters after each 5 bag
changes.
Cleaning the pre-motor lter:
1. Lift the bag door release latch [13] to open the cover and remove the bag holder.
2. To remove the pre-motor lter slide the pre-motor lter frame from the cleaner. [16]
3. Remove the lter from the holder. [17]
4. Wash it in hand warm water, [20] and allow it to dry thoroughly before replacing to the
cleaner [21].
Cleaning the exhaust lter:
1. To remove the exhaust lter, unclip the exhaust lter cover [18] and remove the lter pack.
[19]
2. Wash the lter in hand warm water [20] and allow it to dry thoroughly before replacing to
the cleaner. [21].
Remember: Do not use hot water or detergents. In the unlikely event of the lters becoming
damaged, t a Genuine Hoover replacement. Do not try and use the product without a dust
bag or lter tted.
Cleaning the permanent cloth dust bag*
To maintain optimum performance we recommend that you wash the permanent cloth dust
bag under hand warm water after every 5 full bags. Remove excess water and leave to dry fully
before replacing.
ACCESSORIES AND NOZZLES
*Certain models only
**Nozzle design may vary according to model
2
GB
Removing a Blockage From The System
If the bag check indicator is illuminated or ashing:
1. Check if the bag is full. If so refer to ‘Replacing The Dust Bag’.
2. If it is not full, then;
A. Do the lters need cleaning? If so refer to ‘Cleaning the Filter’.
B. Check if there is any other blockage in the system - Use a rod or a pole to remove any
blockage from the Teletube or exible hose.
Warning - The bag check indicator will turn red if the cleaner is used when full, if there is a
blockage or if the lters are dirty. If the cleaner is used for a signicant period of time with the
bag check indicator is red, a thermal cut out will switch the cleaner o to prevent overheating.
The bag check indicator turn green once the cleaner has switched o to signal that the thermal
cut out has been activated. If this should happen, switch the cleaner o, unplug and correct the
fault. It will take about 30 minutes for the cut out to automatically reset.
All accessories can be tted to the end of the handle or the end of the tube. [23]
2 in 1 tool – Combines two functions in one, the 2 in 1 tool can be connected as a crevice tool.
By rotating the end piece converts to a dusting brush. The 2 in 1 tool can be stored neatly at
the rear of the cleaner. [22]
Crevice Tool – For corners and hard to reach areas.
Dusting Brush – For bookshelves, frames, keyboards and other delicate areas. To extend the
brushes push the button on the body of the tool.
Pet Hair Remover Mini Turbo Nozzle* – Use the mini turbo nozzle on stairs or for deep
cleaning on textile surfaces and other hard to clean areas [1T].
Allergen Remover Mini Turbo Nozzle* – Use the mini turbo nozzle on stairs or for deep
cleaning on textile surfaces and other hard to clean areas. [1U]
Grand Turbo Nozzle* – Use the turbo nozzle for deep cleaning on carpets. [1V]
Hard Floor Caresse Nozzle*– For wooden oors and other delicate oors. [1W]
IMPORTANT: Do not use the grand turbo nozzle or mini turbo nozzles on rugs with long
fringes, animal hides and carpet pile deeper than 15mm. Do not keep the nozzle stationary
while the brush is rotating.
