[SR] STRONGLY RECOMMENDED to report support for feature android.hardware.audio.pro via

the android.content.pm.PackageManager class.

If device implementations include a 4 conductor 3.5mm audio jack, they:

[C-2-1] MUST have the continuous round-trip audio latency to be 20 milliseconds or less

over the audio jack path.

[SR] STRONGLY RECOMMENDED to comply with section Mobile device (jack)

specifications of the Wired Audio Headset Specification (v1.1) .

The continuous round-trip audio latency SHOULD be 10 milliseconds or less over the

audio jack path.

If device implementations omit a 4 conductor 3.5mm audio jack and include a USB port(s) supporting

USB host mode, they:

[C-3-1] MUST implement the USB audio class.

[C-3-2] MUST have a continuous round-trip audio latency of 20 milliseconds or less over

the USB host mode port using USB audio class.

The continuous round-trip audio latency SHOULD be 10 milliseconds or less over the USB

host mode port using USB audio class.

If device implementations include an HDMI port, they:

[C-4-1] MUST support output in stereo and eight channels at 20-bit or 24-bit depth and

192 kHz without bit-depth loss or resampling, in at least one configuration.

5.11. Capture for Unprocessed

Android includes support for recording of unprocessed audio via the

android.media.MediaRecorder.AudioSource.UNPROCESSED audio source. In OpenSL ES, it can be accessed

with the record preset SL_ANDROID_RECORDING_PRESET_UNPROCESSED .

If device implementations intent to support unprocessed audio source and make it available to third-

party apps, they:

[C-1-1] MUST report the support through the android.media.AudioManager property

PROPERTY_SUPPORT_AUDIO_SOURCE_UNPROCESSED .

[C-1-2] MUST exhibit approximately flat amplitude-versus-frequency characteristics in the

mid-frequency range: specifically ±10dB from 100 Hz to 7000 Hz for each and every

microphone used to record the unprocessed audio source.

[C-1-3] MUST exhibit amplitude levels in the low frequency range: specifically from ±20 dB

from 5 Hz to 100 Hz compared to the mid-frequency range for each and every

microphone used to record the unprocessed audio source.

[C-1-4] MUST exhibit amplitude levels in the high frequency range: specifically from ±30

dB from 7000 Hz to 22 KHz compared to the mid-frequency range for each and every

microphone used to record the unprocessed audio source.

[C-1-5] MUST set audio input sensitivity such that a 1000 Hz sinusoidal tone source

played at 94 dB Sound Pressure Level (SPL) yields a response with RMS of 520 for 16 bit-

samples (or -36 dB Full Scale for floating point/double precision samples) for each and

every microphone used to record the unprocessed audio source.

[C-1-6] MUST have a signal-to-noise ratio (SNR) at 60 dB or higher for each and every

microphone used to record the unprocessed audio source. (whereas the SNR is measured
