All SPL measurements are made directly next to the microphone under test. For multiple microphone
configurations, these requirements apply to each microphone.
If device implementations declare android.hardware.microphone but do not support unprocessed audio
source, they:
[C-2-1] MUST return null for the
AudioManager.getProperty(PROPERTY_SUPPORT_AUDIO_SOURCE_UNPROCESSED) API method,
to properly indicate the lack of support.
[SR] are still STRONGLY RECOMMENDED to satisfy as many of the requirements for the
signal path for the unprocessed recording source.
6. Developer Tools and Options Compatibility
6.1. Developer Tools
Device implementations:
[C-0-1] MUST support the Android Developer Tools provided in the Android SDK.
Android Debug Bridge (adb)
[C-0-2] MUST support all adb functions as documented in the Android SDK
including dumpsys .
[C-0-3] MUST NOT alter the format or the contents of device system events
(batterystats , diskstats, fingerprint, graphicsstats, netstats, notification,
procstats) logged via dumpsys.
[C-0-4] MUST have the device-side adb daemon be inactive by default and
there MUST be a user-accessible mechanism to turn on the Android Debug
Bridge.
[C-0-5] MUST support secure adb. Android includes support for secure adb.
Secure adb enables adb on known authenticated hosts.
[C-0-6] MUST provide a mechanism allowing adb to be connected from a host
machine. For example:
Device implementations without a USB port supporting peripheral
mode MUST implement adb via local-area network (such as
Ethernet or Wi-Fi).
MUST provide drivers for Windows 7, 9 and 10, allowing developers
to connect to the device using the adb protocol.
Dalvik Debug Monitor Service (ddms)
[C-0-7] MUST support all ddms features as documented in the Android SDK.
As ddms uses adb, support for ddms SHOULD be inactive by default, but
MUST be supported whenever the user has activated the Android Debug
Bridge, as above.
Monkey
[C-0-8] MUST include the Monkey framework and make it available for
applications to use.
SysTrace
[C-0-9] MUST support systrace tool as documented in the Android SDK.
Systrace must be inactive by default and there MUST be a user-accessible
mechanism to turn on Systrace.
6.2. Developer Options
Page 65 of 118
