1 PRODUCT INTRODUCTION

1.1 General Introductions

The Saramonic SmartMixer is a compact and lightweight audio mixer with phantom power and amplifier, ideal for iOS and Android

mobile devices video production.

The mixer features one mini XLR input for balanced microphones and two microphone/line inputs for the included condenser

microphones or other user-supplied microphones. A volume control knob and level meter allow easy adjustment of the input level. A

headphone monitor output allows you to monitor the input and playback signal.

It comes with an aluminum handgrip for recording on the move, or it can be mounted on a tripod for stationary use. The included

device holder allows the SmartMixer to be used in either landscape or portrait orientations.

• +48V phantom power

• One 1/8”(3.5 mm) stereo line output to phone

• One 1/8”(3.5 mm) headphone monitor output

20 Hz to 20 Khz (+/-0.5 dB)

82 dB @ 1 kHz, -30 dBu input

less than 0.03% @ 1 kHz, -30 dBu input

15 dB

15 dB

5V power supplies

48V power supplies

• Independent L/R level meters

• Volume control knob

• Includes two plug-in power condenser microphones

• Includes a device holder and aluminum hand grip

• Power provided by 9V battery

Condenser Microphones

Cold Shoe

Mini XLR Microphone Input

Volume Control Knob

Hand Grip

1.3 Specifications

Output Cable

for Android
