CRUSH MINI - PANEL FEATURES CRUSH MINI - REAR FEATURES
SHAPE: Adjusts the tonal
response. Turning clockwise
reduces mids and produces
brighter tones. Turning fully
clockwise ‘scoops’ the mids
entirely.
Turning anticlockwise
increases the mids and
smooths the treble.
TUNER
The chromatic display shows
which note you are playing.
The pitch indicator shows if
the note is flat or sharp. Adjust
the pitch in the direction
shown until the OK LED is lit.
VOLUME: Adjusts the overall
output volume. Experiment
with the Gain control to achieve
the desired balance. Set to
the minimum position before
switching the unit ON. When
using the Phones output, keep
the Volume control low to
avoid overloading headphones
or the input of your
mixer/recording console.
GAIN: Adjusts the gain level.
A variety of tones can be
achieved, from clean (low
setting) to heavy distortion
(higher settings) and
everywhere in between.
Note: With the Gain set to
minimum, no sound will be
heard.
INPUT
This is the input of the unit for
your guitar which also acts as
a power switch. Connecting
the jack will allow the unit to
be turned on
PHONES
The headphone output
disengages the speaker
output for silent practice.
CAUTION: Headphones used
for extended periods of time
at extremely loud levels may
cause hearing damage.
DC IN
The Crush Mini can be
powered by 9V or 12V DC. A
regulated DC power supply
fitted with a centre negative
plug (2.1mm) must be used.
AUX IN
Connect external devices
(Laptop, MP3 player etc.) to
the AUX IN via a 3.5mm
audio cable. Audio is summed
to mono. Connecting a jack to
the AUX IN will allow the unit
to be turned on.
SPEAKER OUT
The Crush Mini can be used
to power an external speaker
with a rating of 8Ω or more.
This will disconnect the
internal speaker. Always use a
dedicated speaker cable.
16Ω
MONO
