1 & 4. LEFT/RIGHT LINK: sends to the output the same signal coming from

LEFT/RIGHT INPUT connector. This allow the cascade connection of different

devices to the same sound source.

2 & 5. LEFT/RIGHT INPUT: XLR input socket for connection of the signal to be

amplified.

3. 180° Ph: inverts input signal phase.

6. LEDs:

- ON LED: indicates that the speaker is On.

- Prot. LED: indicates that the internal amplifier switched to protection mode

due to a fault of the amplifier itself or of the connected speakers (please call

the technical support).

- Temp. LED: indicates that the internal amplifier switched to protection

mode due to excessive heating. In this condition, the amplifier supply half

the normal power. Please reduce the input signal to allow the restore of

normal load conditions.

- Comp. LED: indicates activity of the compressor. If the signal passes over a

safety threshold, the compressor guarantees a good quality playback without

acoustic distortion, damping the appropriate signal frequencies. The system

operates in total safety. If the LED is constantly On, there is an excess of

signal. In this case, please reduce the incoming signal level.

- Sign. LED: indicates that the signal is present.

7. Gain: to adjust the signal gain in range from -35dB to 0dB.

8. Mains In: connect the mains cable supplied from the factory with the

loudspeaker to this socket.

9 & 11. AC Power Out: easily connect up to other two VERSE speakers to the

mains. Pay attention not to exceed the limit reported on the chassis near to

the connectors.

10. POWER: Switches the power on/off.
