RCF HL 2240 [14/28] Specifications

ENGLISH

SPECIFICATIONS

HL 2240 HL 2260 HL 2290 HS 2200

SYSTEM

FREQUENCY RANGE (–10 dB) 60 Hz ÷ 20 kHz 30 ÷ 200 Hz

FREQUENCY RANGE (–3 dB) 80 Hz ÷ 20 kHz 35 ÷ 200 Hz

HOR. COVERANGE ANGLE (–6 dB) 40° 60° 90° -

VERT. COVERANGE ANGLE (–6 dB) 22.5° 22.5° 22.5° -

DIRECTIVITY FACTOR (Q) 16 14 13 -

SENSITIVITY (1 W, 1 m) WF: 104 dB, TW: 113 dB 100 dB

MAX. SOUND PRESSURE LEVEL

(peak power, 1 m)

141 dB 136 dB

INPUT NOMINAL POWER (RMS) WF: 1350 W, TW: 150 W 900 W

INPUT PEAK POWER WF: 5400 W, TW: 600 W 3600 W

RECOMMENDED AMPLIFIER WF: 2700 W, TW: 300 W 1800 W

SUGGESTED CROSSOVER FREQ. 600 Hz 80 ÷ 120 Hz

LOW FREQ. TRANSDUCERS

NUMBER AND TYPE 2 x 12” woofer (3.5” voice coil)

1 x 18” woofer

(4” voice coil)

NOMINAL IMPEDANCE 8 Ω 8 Ω

AES POWER RATING 1350 W 900 W

SENSITIVITY (1 W, 1 m) 104 dB 100 dB

HI FREQ. TRANSDUCERS

NUMBER AND TYPE 1 x 1.5” compression driver (4” voice coil) -

NOMINAL IMPEDANCE 8 Ω -

AES POWER RATING 150 W -

SENSITIVITY (1 W, 1 m) 113 dB -

PHYSICAL

ENCLOSURE Trapezoidal, 15 mm birch plywood construction

RIGGING INSERTS Side and rear array rigging points

COLOUR Polyurea black, weather and scratch resistant paint

GRILLE Custom perforated steel grille

INPUT CONNECTORS Amphenol eco/mat IP 67

DIMENSIONS (w, h, d) 771 mm (30.35”), 530 mm (20.87”), 635 mm (25.00”)

NET WEIGHT 62 kg (137 lbs) 60 kg (132 lbs) 62 kg (137 lbs) 60 kg (132 lbs)
