T: +44 (0) 20 3008 7530 W: www.soundnetwork.co.uk 430 Highgate Studios, 53-79 Highgate Road, London, NW5 1TL

Product Details

DPA SC4060

Miniature Omnidirectional Microphone, Hi-Sens

The DPA d:screet™ SC4060 Miniature Omni mic is a long-standing versatile

workhorse that adapts to nearly any recording situation and now features a re-

inforced cable relief that makes the d:screet SC4060 robust and durable, while

maintaining a very small footprint.

True to form, the industry leading DPA d:screet SC4060 microphone has very

low self noise and extremely high sensitivity, offering the most clear, transpar-

ent and natural sound available from any miniature microphone. the SC4060 is

capable of handling 134 dB peak before clipping, and with a linear response

and low distortion and an extremely large dynamic range, they handle almost

any situation with ease.

The d:screet Miniature Omnidirectional mics and accessories are designed for

a broad range of applications. Whether reproducing a voice or instrument for

lm, theatre, television, video or any other close-miking situations, these DPA

mics will not disappoint.

DPA have equipped the d:screet SC4060 with their unique Double Vent Pro-

tection system allowing for greater resistance to humidity and sweat. These

new 4060 miniature mics also have a new reinforced cable relief, built to with-

stand the constant bends, twists and pulls that are inevitable in everyday use.

To add to the durability, the d:screet SC4060 cable is reinforced with kevlar

and the diaphragm and microphone capsule housing are both gold treated,

meaning the new SC4060 is made to endure.

Specications:

Directional characteristics: Omnidirectional

Principle of operation: Pressure

Cartridge type: Pre-polarised condenser element with vertical diaphragm

Frequency range, ± 2dB: Soft boost grid:20Hz - 20kHz, 3dB soft boost at 8 - 20 kHz; High boost grid: 20Hz - 20kHz, 10dB

boost at 12kHz

Sensitivity, nominal, ± 3 dB at 1kHz: 20mV/Pa; -34dB re. 1 V/Pa

Equivalent noise level, A-weighted: Typ. 23dB(A) re. 20 µPa (max. 26 dB(A))

Equivalent noise level, ITU-R BS, 468-4: Typ. 35dB (Max 38dB)

S/N Ratio, re. 1kHz at 1Pa(94 dB SPL): 71dB(A)

Total Harmonic Distortion (THD): <1% up to 123dB SPL peak; <1% up to 120dB SPL RMS sine

Dynamic range: Typ. 100dB

Max. SPL, peak before clipping: 134dB

Output impedance: 30 - 40Ω

Cable Drive capability: Up to 300 m (984 ft)

Power supply:

Wireless systems: Min 5V to max. 50V through DPA adapter.

With DPA XLR adapter: 48V phantom power ±4V.

Connector: MicroDot

Microphone weight: 7.5g incl. cable and MicroDot connector

Microphone diameter: 5.4mm (0.21in)

Microphone length: 12.7mm (0.5in)

Cable length: 1.8m (6ft) Cable diameter: 1.6mm (0.06in)

Colours available: Black, Beige, Brown and White

Polarity: Polarity increasing sound pressure produces positive going voltage on MicroDot pin.
