MAIN ELECTRICAL CHARACTERISTICS:

Input Voltage Range : Vin 90 - 260 VAC

Frequency : 50 - 60 Hz

Power Consumption: 150W

Power Factor (Pf) : 0.95 electronic PFC controller

Efficiency : 90% typical

Output:

Output Current : 350 mA @ 100% per channel (500 mA @ 100% per channel in Boost Mode)

Output Voltage : Vout 24V

Control Input:

Control Signal : DMX 512

Dimming System :Constant Current PWM

Address Range : DMX 512 channels addressable by display

ACCESSORIES

• Lenses set Spot available for each model

• Lenses set Medium flood available for each model

• Lenses set Wide flood available for each model

IMPORTANT SAFETY INFORMATION

Fire prevention:

Never locate the fixture on any flammable surface.

Minimum distance from flammable materials: 10 cm.

Replace any blown or damaged fuses only with those of identical value.

Prevention from electric shock:

High voltage is present inside the unit.

Unplug the unit prior to performing any operation which involves touching the inside of the unit.

This equipment must be grounded, do not connect to non-grounded supplies.

Use only AC supplies 90-260V, 50-60Hz.

The unit should never be located in position exposed to rain or in areas of extreme humidity.

A good air ventilation is essential for proper equipment work.

Safety:

The external surface of the unit may exeed 50°C; never handle the unit until at least 5 minutes

have elapsed since the unit was turned off.

Never install the unit in an enclosed area lacking sufficient air flow.

The ambient temperature should not exeed 40°C and should not be lower than -10°C.

The use of a thermal magnetic circuit breaker is recommended for each FOS 100 DYNAMIC unit.

FOS 100 DYNAMIC
