Dynacord A 112 Руководство по эксплуатации онлайн
Features:
• DH-1K 1.5-inch Titanium Diaphragm Compres-
sion Driver
• EVS-12K 12-inch Woofer
• 94 dB SPL sensitivity, 124 dB max. SPL
• 250 W continuous, 1000 W peak power
• 15 mm Plywood Enclosure
Engineering Data Sheet
A 112
12-inch two-way full-range cabinet, passive
Wir weisen ausdrücklich darauf hin, dass bei
gehängten Lautsprecherboxen die einschlägigen
Sicherheitsbestimmungen zu beachten sind. Es
muss unbedingt qualifizierte Fachberatung in
Anspruch genommen werden!
We expressly point out that the relevant safety
regulations must be observed for “flying”
loudspeaker systems. It is imperative that quali-
fied expert advice is sought.
Order No. A112: F01U270185
Cabinet Full Range
Nominal impedance 8 Ohms
Minimum impedance 7.0 Ohms
Power Handling
continuous 250 W
program 500 W
peak 1000 W
Max. SPL (calculated with peak
power)
124 dB
Axial Sensitivity 94 dB
Frequency Range (-10 dB) 55 Hz to 20 kHz
Frequency Response (-3 dB) 82 Hz to 18 kHz
Recommended HP Frequency 45 Hz
Coverage (Horizontal x Vertical) 90° x 50°
LF Transducer 1 x EVS-12K, 305 mm (12“),
F01U250937
HF Transducer DH-1K, 39 mm (1.5“), Titanium Dia-
phragm Compression Driver,
F01U250928
Crossover Frequency 2.1 kHz
Connectors 2 x NL4-type
Enclosure Material 9-ply, 15 mm Plywood, internally braced,
with textured paint
Grille 18GA Steel with black powdercoat
Handles 1
Product Dimensions (H x W x D) 607 x 362 x 340 mm
Shipping Dimensions (H x W x D) 683 x 430 x 410 mm
Net Weight 16.0 kg
Shipping Weight 20.3 kg
Warranty 5 years
Optional Accessories
VPM 1500, variable speaker pole F01U141047
BS 35, speaker stand F01U141046
SH-A112, Dust Cover F01U270395
Recommended extensions
A 118 Subwoofer F01U270187
