Using the SKP 100 G4
91
Switching the SKP 100 G4 plug-on transmitter on
and off
To switch on the SKP 100 G4:
▷ Hold down the ON/OFF button until the Sennheiser logo appears on the
display.
To switch off the SKP 100 G4:
▷ Hold down the ON/OFF button until the display goes off.
