ELECTRO VOICE EVID FM4.2 [2/2] Evid in wall speaker product specifications

©2007 Telex Communications, Inc. PA#20688

EVID FM4.2 EVID FM6.2

Freq. Response (-3 dB): 70 Hz - 20 kHz 60 Hz - 20 kHz

Freq. Range (-10 dB): 52 Hz - 20 kHz 52 Hz - 20 kHz

Axial Sensitivity: 87 dB (SPL 1W/1m) 90 dB (SPL 1W/1m)

Impedance: 8 ohms nominal (transformer bypass) 8 ohms nominal (transformer bypass)

Crossover Frequency: 3.6 kHz 3.3 kHz

Rec. Highpass Frequency: 70 Hz 60 Hz

HF Transducer: 1 in. (25.4 mm) 1 in. (25.4 mm)

Enclosure Material: Baffle: UL 94V-O rated ABS Baffle: UL 94V-O rated ABS

Backcan: Zinc plated steel Backcan: Zinc plated steel

Grille: Perforated powder coated steel with safety tether Perforated powder coated steel with safety tether

Mounting System: Integrated toggle anchors Integrated toggle anchors

Support Hardware: Cutout template, Paint Shield Cutout template, Paint shield

Dimensions: 349.9mm x 188.3mm x 96.5mm 465.4mm x 256.4mm x 100.3mm

(13.77” x 7.42” x 3.80”) (18.32” x 10.09” x 3.95”)

Net Weight (Each): 2.9 kg (6.5 lb) 5.8 kg (12.7 lb)

Shipping Weight (Pair): 6.8 kg (15.0 lb) 12.9 kg (28.4 lb)

Common Key Features:

Fax: 1-800-955-6831

Canada–Ph: 1-866-505-5551

Fax: 1-866-336-8467

Latin America–

Ph: 1-952-887-5532

Fax: 1-952-736-4212

Fax: +49 9421 706-265

France: EVI Audio France S.A.,

Parc de Courcerin,

Allée Lech Walesa,

F 77185 Lognes, France

Phone: +33 1-6480-0090

Fax: +33 1-6006-5103

Asia & Pacific Rim–

Headquarter Asia

Singapore: Telex Communications

(SEA) Pte Ltd

38C Jalan Pemimpin

Singapore 577180

Tel: (65) 6319 0621

Fax: (65) 6319 0620

Hong Kong: Telex EVI Audio

(HK) Ltd.

Unit 5,1/F, Topsail Plaza

11 On Shum Street

Shek Mun,Shatin HK

Phone: +852 2351-3628,

Fax: +852 2351-3329

Shanghai, China

Postal Code: 200070

Tel: +86 21-6317-2155

Fax : +86 21-6317-3025

EVID In-Wall Speaker Product Specifications:

• Either 70v/100v or 8 ohm operation is

standard on both models. No need to

buy or stock special versions.

• Shallow prole allows installation

virtually anywhere.

connectors for easy wiring

and installation.

• Four point “quick mounting” tabs

provide fast easy installation in any

• The transformer is mounted on the

rear can surface to further enhance

stiffness.

• Specially designed ribbed back can

is designed to eliminate flexing.
