CHAUVET COLORdash Par Hex 7 [3/36] Ac power
![CHAUVET COLORdash Par Hex 7 [3/36] Ac power](/views2/2008317/page3/bg3.png)
COLORdash™ Par-Hex 7 QRG EN
3
AC Power
This product has an auto-ranging power supply that can work with an input voltage
range of 100–240 VAC, 50/60 Hz.
To eliminate unnecessary wear and improve its lifespan, during periods of
non-
use completely disconnect the product from power via breaker or by
unplugging it.
Power Linking
You can link up to 27 COLORdash™ Par-Hex 7 products at 120 V, 46 products at
208 V, or 52 products
at 230 V. Never exceed this number. Power linking cords
can be purchased separately.
AC Plug
Connection
Wire (U.S.)
Wire (Europe)
Screw Color
AC Live
Black
Brown
Yellow/Brass
AC Neutral
White
Blue
Silver
AC Ground
Green/Yellow
Green/Yellow
Green
Replacing The Fuse
1. Disconnect this product from power.
2. Using a flathead screwdriver, unscrew the fuse holder cap from the housing.
3. Remove
blown fuse and replace with a good fuse of the same type and rating.
4. Screw the fuse holder cap back in place and reconnect power.
DMX Linking
The COLORdash™ Par-Hex 7 will work with a DMX controller using a
3- or 5-pin DMX serial connection. A DMX Primer
is available from
www.chauvetprofessional.com.
DMX Connection
The COLORdash™ Par-Hex 7 uses a 3- or 5-pin DMX data connection for its
DMX personalities: 6 Ch, 8 Ch, 12Ch, 13Ch, HSI, and HSV. See the
User
Manual for information about connecting and configuring the product
for DMX
operation.
Note: For optimum control of the 16-
bit dimming channels in the 13Ch
personality, be sure that Dim mode is set to Off.
Master/Slave
Connection
The COLORdash™ Par-Hex 7 uses the DMX data connection for its Master/Slave
mode. See the User Manual for information about connect and configure
the
product for master/slave operation.
