ÉPIX Strip IP QRG Rev. 2

QUICK REFERENCE GUIDE

Technical Specifications

Dimensions and Weight

Note: Dimensions in inches are rounded.

Power

Light Source

Photometrics

Control

Thermal

Ordering

Filter Length Width Height Weight

Square Milky Filter 39.37 in (1000 mm) 3.93 in (100 mm) 1.33 in (34 mm) 6 lb (2.7 kg)

Black Stealth Filter 39.37 in (1000 mm) 3.46 in (88 mm) 1.33 in (34 mm) 6 lb (2.7 kg)

Round Milky Filter 39.37 in (1000 mm) 5.03 in (128 mm) 1.77 in (45 mm) 6 lb (2.7 kg)

Power Supply Range Power Linking

ÉPIX Drive 2000 IP 100 to 240 VAC, 50/60 Hz 10 per ÉPIX Drive 2000 IP port

Parameter 120 V, 60 Hz 208 V, 60 Hz 230 V, 50 Hz

Consumption 35 W 44 W 44 W

Operation Current 0.292 A 0.210 A 0.195 A

Power I/O U.S./Worldwide UK/Europe

Power Input Connector IP65 4-pin XLR IP65 4-pin XLR

Power Cord Plug IP65 4-pin XLR IP65 4-pin XLR

Type Color Quantity Lifespan

SMD 505 LED Tri-color RGB 100 50,000 hours

Parameter Square Milky Filter Black Stealth Filter Round Milky Filter

Viewing Angle 160° 140° 160°

Illuminance 2,470 NITS 1,455 NITS 1,360 NITS

Pixel Pitch 10 mm 10 mm 10 mm

Refresh Rate 4,800 Hz 4,800 Hz 4,800 Hz

Data I/O Channel Range (Art-Net™/sACN) Channel Range (Kling-Net)

IP65 4-pin XLR 15, 17, 30, 60, 150 or 300

Determined by ArKaos MediaMaster

software

Maximum External Temp. Cooling

113 °F (45 °C) Convection

Product Name Item Name Item Code UPC Number

ÉPIX Strip IP EPIXSTRIPIP 03091318 781462216665
