COLORado 1 Solo QRG EN

Mounting

Before mounting this product, read the Safety Notes. Use at least one mounting

point per product. Make sure the mounting clamps are capable of supporting the

weight of the product. For our CHAUVET Professional

line of mounting clamps,

go to http://trusst.com/products/.

Product

Mounting

Diagram

Control Panel

Description

Button

Function

<MENU>

Exits from the current menu or function

<ENTER>

Enables the currently displayed menu or sets the currently

selected value into the selected function

<UP>

Navigates upwards through the menu list or increases the

numeric value when in a function

<DOWN>

Navigates downwards through the menu list or decreases

the numeric value when in a function

Passcode

After being prompted, enter the following passcode by pressing:

This passcode cannot be changed and must be used whenever prompted.

Secure the safety cable using

the passageway on the back

of the product.

Overhead Mounting

Floor Mounting

Mounting Clamp

Safety Cable
