Behringer X32 CORE [4/4] Specifications

Page 4 of 4

For service, support or more information contact the BEHRINGER location nearest you:

This device has not been authorized by the rules of the Federal Communications Commission. This device is not, and may not be, offered for sale or lease, or sold or leased in the 50 U.S. states, the District of Columbia and U.S. possessions, until authorization is obtained.

Technical specifications and appearances are subject to change without notice and accuracy is not guaranteed. BEHRINGER, KLARK TEKNIK, MIDAS, BUGERA, and TURBOSOUND are part of the MUSIC Group (music-group.com). FireWire, iPhone, and iPad are trademarks of Apple Inc.,

registered in the U.S. and other countries. The AES50 trademark is a property of the Audio Engineering Society, NY. All trademarks, including, but not limited to Lexicon, PCM, EMT, Quantec and QRS are trademarks or registered trademarks of their respective owners. Their use neither

constitutes a claim of the trademarks nor affiliation of the trademark owners with MUSIC Group. Product names are mentioned solely as a reference for X32 CORE compatibility and effects. MUSIC Group accepts no liability for any loss which may be suffered by any person who relies

either wholly or in part upon any description, photograph or statement contained herein. Colors and specifications may vary from actual product. MUSIC Group products are sold through authorized fulfillers and resellers only. Fulfillers and resellers are not agents of MUSIC Group

and have absolutely no authority to bind MUSIC Group by any express or implied undertaking or representation. This manual is copyrighted. No part of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and

recording of any kind, for any purpose, without the express written permission of MUSIC Group IP Ltd. ALL RIGHTS RESERVED © 2013 MUSIC Group IP Ltd. Trident Chambers, Wickhams Cay, P.O. Box 146, Road Town, Tortola, British Virgin Islands.

Tel.: +81 3 6231 0454

Email: CARE@music-group.com

Specications

Processing

Number of processing channels 32 input channels,

8 aux in channels,

8 FX return channels,

16buses, 6matrices,

mainLRC

Internal eects engines, 8 / 16

D/A CS4385)

Local I/O latency (local in > 0.8 ms

console processing* > local out)

Networked I/O latency 1.1 ms

> stagebox out)

Total number of accessible input 128 / 144

P-16 connector, Ultranet 1

(no power supplied)

MIDI inputs / outputs 1 /1

Ethernet, RJ45, rear panel, 1

for remote control

USB Type A, top panel, 1

Preamp Design MIDAS

THD + noise, 20 dB gain, < 0.006% A-weighted

0 dBu out

Input impedance XLR, 5 kΩ / 10 kΩ

CMRR, XLR, @ 20 dB gain (typical) > 70 dB

CMRR, XLR, @ 40 dB gain > 80 dB

sample rate, 0 dB to -1 dB

Dynamic range* analog in 106 dB

A/D Dynamic range* preamp 109 dB

and converter (typical)

D/A Dynamic range*, 108 dB

Cross talk rejection @ 1 kHz, 100 dB

Input impedance TRS Jack, 20 kΩ / 40 kΩ

Non clip maximum input level, TRS +16 dBu

Nominal output level, TRS +4 dBu / +16 dBu

Output impedance, 150 Ω / 300 Ω

TRS, unbal. / bal.

Phones output impedance / level 40 Ω / +25 dBm (stereo)

Channel Selector LCD Screen (1 pcs) 128x64, LCD with RGB

colorbacklight

Switch-mode autorange 100-240 V (50/60 Hz)

Weight 7.9 lbs / 3.6 kg
