Rode NTG-8 [7/12] Mounting the ntg8

• To mount the NTG8 in the supplied SM8

shockmount, insert the base of the microphone

(with the XLR connector) into the rubber opening

closest to the grey cable management clips and

slide the microphone through all four rubber

mount openings.

Some pressure will need to be applied to insert

the microphone, as the openings must be tight to

secure the microphone.

Mounting the NTG8

NTG8 correctly mounted in SM8 shockmount

(note SM8 orientation)

NTG8 incorrectly mounted in SM8 shockmount
