NT2-A

Specifications

Acoustic Principle: Externally polarized 25 mm

(1”) dual diaphragm.

Active Electronics: J-FET impedance converter

with bipolar output buffer.

Pickup Pattern: Multi-pattern (see graphs below)

Frequency Response: 20 Hz ~ 20 kHz (see graphs)

Output Impedance: 200 Ω

Sensitivity: -36 dB re 1 Volt/Pascal

(16 mV @ 94 dB SPL) +/-2 dB

Equivalent Noise: 7 dBA SPL

(per IEC651, IEC268-15)

Maximum Output: +16 dBu (@ 1% THD into 1 kΩ)

Dynamic Range: 140 dB (per IEC651, IEC268-15)

Maximum SPL: 147 dB (@ 1% THD into 1 kΩ)

157 dB (@ 1% THD into 1 kΩ)

with pad at -10 dB (max)

Signal/Noise: 87 dB (per IEC651, IEC268-15)

Power Requirements: Phantom 48 Volts (P48 Standard).

Features

• Australian designed and manufactured HF1 - 1” edge

terminated, gold sputtered, dual 5 um diaphragm capsule.

• 3 position variable polar pattern: Omni, Cardioid or

Figure 8; all controlled at the mic.

• 3 position variable high-pass lter: 0 dB, -5 dB, and -10 dB.

• 3 position variable pad: Flat, 80 Hz or 40 Hz.

• Ultra low noise, transformer less SMT circuitry.

• Wide dynamic range.

• High strength welded and heat-treated steel mesh head.

• Durable satin nickel nish.

• Internal capsule shock mounting.

• Supplied complete with M2 Mount and Pouch.

• Designed and manufactured in Sydney, Australia.
