RecognizingChords
StyleControl
24
DefaultmodeforA.B.C.isoffonthepiano.
Pressbuttontoturnonthis"autobass
chord"function.Theleftsectionofthekeyboardisknown
asthe"chordarea",whileplayingthechord,boththebass
andthechordvoicessound.
[CHORDMODE]
Thereare2waystodetectthechord:singlefingerdetectandmultifingerdetect.""""
SingleFingerChords
Ifthechordplayedisbasedon"multifingerdetect",itisrecognizedasthe"multifingerchords".
Ifnot,"singlefingerchord"willberecognized.
Thismethodallowsyoutoeasilyplaychords
intheaccompanimentrangeofthekeyboard
usingonlyone,two,orthreefingers.
TheexamplesofSingleFingerChord"C,Cm,
C7andCm7"areshownasbelow:
Toplayamajorchord
Presstherootnoteofthechord
Toplayaminorchord
Presstherootnotetogetherwiththe
nearestblackkeytotheleftofit.
Toplayaseventhchord
Presstherootnotetogetherwiththe
nearestwhitekeytotheleftofit.
Toplayaminorseventhchord
Presstherootnotestogetherwith
thenearestwhiteandblackkeysto
theleftofit(threekeysaltogether).
MultiFingerChords
Thismethodallowsyoutoproduceanaccompa-
nimentbyplayingchordswithnormalfingerings
intheaccompanimentrangeofthekeyboard.
ToplayMultiChords(ExampleinCchords)
Atotalof32chordsareprovidedasbelow:
Notesenclosedinparenthesesareoptional;
thechordscouldberecognizedwithoutthem.
WhenA.B.C.ison,pressthekeysontheleftofsplitpoint.
Thechordwillberecognizedassingle
fingerchords.
SincethechorddetectionofA.B.C.isbasedontheChordRoot
priority,somechordsthatcouldbeplayedundertheChordDictio-
narymaynotberecognisedbyA.B.C.,eg.B6bB6B6(9)
bB69BaugbBaugbBm6Bm6Adim7bBdim7Bdim.
、、、
（）、、、、、、、
START/
STOP
SYNC
STOP
SYNC
START
A FADEB
CHORD
MODE
INTRO/
ENDING
FINGERED
FULLRANGE
