APart SDQ5PIR [2/2] Page 2

WWW.APART-AUDIO.COM

INFO@APART-AUDIO.COM

TECHNICAL SPECIFICATIONS

Speaker type : 2 way bass reflex, active

5.25” woofer, 1” tweeter

Input impedance minijack input A : 5 k ohm

Input sensitivity minijack input A : 175 mV (-15dBV)

Input impedance balanced input B : 22 k ohm

Input sensitivity balanced input B : 175 mV (-15dBV)

Tone control bass : +- 14 dB @ 100 Hz in 2 dB steps

Tone control treble : +- 14 dB @ 10 kHz in 2 dB steps

Balance control : +- 31 steps ; 1.25 dB per step

Input gain adjustment : 0 to 3 ; + 3.75 dB per step

Output power : 2 x 30 watts RMS

Frequency range : 45 - 20000 Hz

THD : <0.07%

S/N ratio : >90 dB

Power supply : 230 VAC / 80 VA max

Standby mode for low power consumption

Fuse rating : 1 AT/250V

Dimensions : Hx W x D (mm) : 252 x 182 x 170

Net weight : 2.85 kg (active) ; 1.75 kg (slave)

Shipping weight : 6.2 kg (1 set)

shipping dimensions : 270 x 210 x 440

Operating temperature : -10 to +40° C

Relative humidity : 10 to 90% non condensing

Remote control unit battery type lithium CR2025 3v

Accessories supplied : Power cord, bracket, manual, infrared remote control unit, connection

wire
