TECHNICAL SPECIFICATIONS

APart CM6E

CEILING SPEAKER

WWW.APART-AUDIO.COM

INFO@APART-AUDIO.COM

The APart CM6E is a dual cone 100V ceiling speaker that is equipped with a High Quality

100 Volt transformer with several power tappings. The CM6E is very well suited for the

distribution of microphone calls, publicity and evacuation messages.

The housing is made of high quality ABS.

The loudspeaker is easy to install, due to its simple, quick mounting system (3 screws which

are hidden behind the loudspeaker grill, what gives the loudspeaker a modern and striking

design).

The CM6E is standard available in white, black and silver colour. From 12 pieces on, the

loudspeakers can be painted optionally in any other RAL colour

CM6E : white RAL 9010

CM6E-BL : black RAL 9011

CM6E-SLV : silver RAL 9006

Type

Woofer

Impedance

Transfo Power Tappings

RMS Power Rated

Music

SPL 1 watt/1 m

Frequency Range

Dispersion @ 1-4 kHz

IP rating

Dimensions Outside dia

Cutout dia

Depth

Weight

Dual Cone

6.5” paper cone

8 Ohm - 100V

1,5 - 3 - 6 watt (6.66k - 3.33k - 1.66k)

6 watt

10 watt

93 dB

70 Hz - 20 kHz

180°-50°

205 mm

183 mm

70 mm

0.95 Kg
