APart CMAR6 [6/12] Specifications

WWW.APART-AUDIO.COM

Specifications

Technical specifications

Specification / Type CMAR5-W CMAR6-W CMAR8-W

Shape: Round Round Round

Rated RMS power: 25W 30W 50W

Music power: 50W 60W 100W

Impedance 8Ohm 8Ohm 8Ohm

Frequency response: 100Hz to 20KHz 70Hz to 20KHz 50Hz to 20 KHz

SPL 1W/1m in dB 85dB 88dB 88dB

Dispersion (at 1kHz, 2kHz,

4kHz, 8kHz in degrees)

180°,120°,120° 180°,180°,90° 180°,100°,60°

HP filter build in: Yes, HP on tweeter Yes, HP on tweeter Yes, HP on tweeter

Woofer size 5

1/4

inch 6

1/2

inch 8 inch

Tweeter size 1 inch 1 inch 1 inch

Color White White White

Chassis Type Plastic Plastic Plastic

Grill material Stainless Steel Stainless Steel Stainless Steel

IP classification IP65 IP65 IP65

Max operating temp 95°C 95°C 95°C

Removable grill: Yes yes Yes

Fixing type: Screws Screws Screws

CutOut dimensions: 110mm 146mm 186mm

Outside dimensions: 152mm 190mm 221mm

Mounting depth: 55mm 61mm 76mm

Net Weight 0.6kg 1kg 1.5kg

Gross Weight: 0.8Kg 1.3Kg 2Kg
