MODEL UV40

Please read these instructions carefully before using this product

IMPORTANT SAFETY INSTRUCTIONS:

1. This portable lamp has a polarized attachment plug (one blade is wider than the other) as a

safety feature. This plug will fit in a polarized outlet. Only one way, if the plug doesn’t fit fully in

the outlet, reverse the plug. If it still doesn’t fit, contact a qualified electrician. Never use with an

extension cord unless the plug can be fully insert. Don’t attempt to defeat this safety feature,

don’t alter the plug. Please mount the unit on wall surface. This unit is used for recreational

illumination for house.

2. Dry locations use only.

3. To reduce risk of fire, replace lamp only with 40W(Max.) T8 tube.

4. Hot surface, keep away from curtains and other combustible materials.

HOW TO INSTALL: (figure 3, figure 4)

The diameter of fixing PIN on the mounting surface shall be between 3mm and 4mm, and its

PIN HEAD’s diameter shall be less than 9mm.( figure 1, figure 2).

bl ack l i ght encl osur e

Assembl ed hol es on t he

VI EWA

f i gur e 1

fi gure 3 (MOUNTING-I)

PI N HEAD

VI EWA

figure2

figure 4 (MOUNTING-II)

Technical Specifications：

Item Code： UV40

Name： FLUORESCENCE LIGHT-40
