Chapter 3 Piano Assembly

Piano Assembly

- Assembly should be carried out by at least two persons.

- Assemble the stand on a hard and flat floor with ample space.

- Be sure to use the included screws, and insert screws of the correct size in the correct

hole locations. Use of incorrect screws can damage the product.

Attach the pedal cord holders to the rear panel

as shown, then clip the cord into the holders

1. Place the pedal box on the left side

panel and use screws to fasten

the side panel.

2. Place the pedal box on the right side

panel and use screws to fasten

the side panel.

3. You can find the pedal cable in the

pedal box . Untie and straighten out

the bundled pedal cable.

1. Fit into the rear panel's hole in the side

panel brackets and then use the screws

to fasten the rear panel.

2. Use the screws to fasten the bottom

of the rear panel.
