Presets
2•2
Saving
Once you’ve edited a preset to your liking, you’ll want to save it in one of the User Banks.
Artist and Song presets can’t be overwritten, so if you want to save an edited version of an
Artist or Song preset, or a custom preset you’ve created from scratch, it must be stored in
one of the 64 memory locations in User Banks 1 thru 16, Channel A, B, C or D.
Here’s an overview of the Save routines for Spider IV:
• L/R Arrows on
4-way Nav Disc
select one of the
14 characters of
the Preset name
[it will flash]
• Up/Down
Arrows select
the next/previous
User Bank as the
Save destination
• Turn Presets
knob to change
the current
character in
Preset name
[push for quick
type change]
• Current Preset
Save destination
[Bank 31 Chan A]
To save a preset:
• Press & hold the channel button of the current preset location - all 4 LEDs will flash
• If you’re starting from an Artist or Song preset, press any A B C or D Channel button
• Select the destination Bank by pressing the up/down arrows on the Nav Disc
• Rename the preset if desired - L/R arrows select character - Presets knob changes it
• Once your preset name is set, press a Channel button as your preset destination
• The LEDs will flash rapidly a few times indicating the Save routine is complete
• Your preset is now saved to the Bank and Channel location you’ve selected
