9 POWERPLAY PRO-8 HA8000/POWERPLAY PRO-XL HA4700 User Manual

POWERPLAY PRO-XL HA4700

Audio Inputs

MAIN IN HFltered servobalanced XLR and

¼" TRS connectors

Input impedance 40 k balanced, 30 k unbalanced

Max. input level 16 dBu balanced and unbalanced

CMRR typically 40 dB, >55 dB @ 1 kHz

AUX IN ¼" TRS connector (stereo)

Input impedance 5 k

Max input level +22 dBu

DIRECT IN ¼" TRS connector (stereo)

Input impedance 15 k

Audio Outputs

MAIN OUT XLR and ¼" TRS connectors, balanced

PHONES OUTPUT ¼" TRS connector (stereo)

Power Amplier

Max. output power +24 dBm (load impedance 100 ),

+21 dBm (load impedance 8 )

Min. output load impedance 8 kΩ

System Specications

Frequency response 10 Hz to 150 kHz, +/-3 dB

Noise 22 Hz to 22 kHz >90 dB @ 0 dBu

Dynamic range 22 Hz to 22 kHz: 110 dB

Distortion (THD) 0.006 % typ. @ +4 dBu, 1 kHz, Gain 1

Function Controls

Input level variable

Balance per channel mix between Aux and Main signals /

balance between right and left channel

Output level per channel variable

Treble cutoff frequency: 6 kHz;

range +/- 12 dB

Bass cutoff frequency: 200 Hz,

range +/- 12 dB

Function Switches

Stereo/2-Channel switches between stereo mode and

2-channel mode

Main in 1 / Main in 2 

Left mute mutes the left signal of the respective

channel

Right mute mutes the right signal of the respective

channel

Mono 

Displays

Input Level 4-digit LED-display: -30/-12/0 dB/CLIP

Output Level 8-digit LED-display:

-30/-24/-18/-12/-6/-3/0 dB/CLIP

Power Supply

Mains voltage

USA/Canada 120 V~, 60 Hz

U.K./Australia 230 V~, 50 Hz

Japan 100 V~, 50 - 60 Hz

General export model 120/230 V~, 50 - 60 Hz

Power consumption 34 W

Fuses 100 - 120 V ~: T630 mA H,

220 - 240 V~: T315 mA H

Mains connection Standard IEC receptacle

Dimensions/Weight

Dimensions (H x D x W) approx. 44.5 x 483 x 217 mm

approx. (1.75 x 19 x 8.5")

Weight approx. 2.5 kg (5.5 lbs)

BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts,

modifications may be made from time to time to existing products without prior notice. Specifications and

appearance may differ from those listed or illustrated.
