13 ULTRAGRAPH PRO FBQ6200/FBQ3102/FBQ1502 User Manual

FBQ1502

Audio Inputs

INPUTS RF-ltered, servo-balanced XLR and

¼" TRS connectors

Impedance 40 kW balanced and unbalanced

Maximum input level +21 dBu balanced and unbalanced

CMRR typ. 40 dB, >55 dB @ 1 kHz

Audio Outputs

S/N ratio 22 Hz to 22 kHz >94 dB @ +4 dBu

Distortion (THD) typ. 0.006% @ +4 dBu, 1 kHz, Gain 1

Crosstalk typ. -65 dB @ 1kHz

Roll-O Filter section

Type 12 dB/oct., Butterworth

Input variable (-15 dB to +15 dB)

Low Cut switchable, Cuto @ 25 Hz

High Cut —

Type analog 15-band equalizer

LED meter —

LED level meter —

FBQ activates the FBQ Feedback

Audio In/Out switch to bypass the equalizer functions

I/O Meter In/Out —

Range shift of the maximum cut/boost range

for all 31/15 bands

Low Cut activates the high pass lter

Pink Noise —

Subwoofer —

Indicators

Subwoofer —

Europe / U.K. / Australia 230 V~, 50 Hz

Japan 100 V~, 50 - 60 Hz

General export model 120/230 V~, 50 - 60 Hz

Power consumption 22 W

Mains connection standard IEC receptacle

(8.5 x 1.8 x 19 x")

Weight 2.34 kg (5.1 lbs)

BEHRINGER continuously strives to assure the highest quality standards possible. Required modifications may

be implemented without prior notice. Technical data and the appearance of the unit may deviate from the above

values and/or illustrations.
