13 XENYX X1204USB/1204USB User Manual

USB

Audio Stereo In/Out

Connector TypeB

Converter 16-bit

Sample Rate 48 kHz

Main Mix System Data

Noise

Main mix @ -∞, -105 dB / -108 dB A-weighted

Channel fader -∞

Main mix @ 0 dB, -95 dB / -97 dB A-weighted

Channel fader -∞

Main Mix @ 0 dB, -82,5 dB / -85 dB A-weighted

Channel fader @ 0 dB

Power Supply

Mains voltage 100 - 240 V~, 50/60 Hz

Power consumption 40 W

Fuse 100 - 240 V~: T 1.6 A H 250 V

Mains connection Standard IEC receptacle

Physical

X1204USB

Dimensions (H x W x D) approx. 3.8 x 10.6 x 12.9"

approx. 97 x 270 x 328 mm

Weight (net) approx. 8.4 lbs / 3.8 kgs

1204USB

Dimensions (H x W x D) approx. 3.8 x 10.6 x 12.9"

approx. 97 x 270 x 328 mm

Weight (net) approx. 6.2 lbs / 2.8 kgs

Measuring conditions:

1: 1 kHz rel. to 0 dBu; 20 Hz - 20 kHz; line input; main output; unity gain.

2: 20 Hz - 20kHz; measured at main output. Channels 1 - 4 unity gain; EQ flat; all channels on main mix; channels

1/3 as far left as possible, channels 2/4 as far right as possible. Reference = +6 dBu.

BEHRINGER is constantly striving to manintain the highest professional standards. As a result of these efforts,

modifications may be made from time to time to existing products without prior notice. Specifications and

appearance may differ from those listed or illustrated.
