7 XENYX X1204USB/1204USB User Manual
2.3.3 Stereo aux return connectors
Fig. 2.8: Stereo aux return connectors
STEREO AUX RETURN 1
The STEREO AUX RETURN 1 connectors generally serve as the return path for the
eects mix generated using the post-fader aux send. This is where you connect
the output signal of the external eects device. If only the left connector is used,
the AUX RETURN automatically operates in mono.
◊ You can also use these connectors as additional line inputs.
STEREO AUX RETURN 2
The STEREO AUX RETURN 2 connectors serve as the return path for the eects
mix generated using the FX control. If these connectors already function as
additional inputs, you can route the eects signal back into the console via a
dierent channel, with the added benet that the channel EQ can be used to
adjust the frequency response of the eects return signal.
◊ In this instance, the FX control of the channel being used as an effects
◊ return should be turned fully counterclockwise, otherwise feedback
problems could occur!
◊ If you wish to use the internal effects processor, no connectors should
be plugged into STEREO AUX RETURN 2.
2.3.4 Stereo aux return
Fig. 2.9: Stereo aux return controls
STEREO AUX RETURN 1
STEREO AUX RETURN 1 is a stereo control which determines the level of the
signal in the main mix. If STEREO AUX RETURN 1 is used as eects return, you can
add the eects signal to any “dry” channel signal.
◊ In this instance, the effects device should be set at 100% effect.
STEREO AUX RETURN MON
The STEREO AUX RETURN MON control has a special function: it can be used to
add an eect to a monitor mix. For example:
Monitor mix with eect
In this instance, the eects device should be set up as follows: AUX SEND 2 is
connected to the L/Mono input of your eects device, while its outputs are connected
to STEREO AUX RETURN 1. Connect the amplier of your monitor system to AUX SEND
1. The AUX SEND 1 master control determines the volume of the monitor mix.
You can now use the STEREO AUX RETURN MON control to adjust the level of the
eects signal routed to the monitor mix.
You can easily use the headphones distribution amplier BEHRINGER POWERPLAY
PRO HA4600/HA4700/HA8000 to provide you with four (or eight with the
HA8000) stereo headphone mixes for your studio.
STEREO AUX RETURN 2 (FX)
The STEREO AUX RETURN 2 control determines the level of signals fed into the
AUX RETURN 2 connectors which are routed to the main mix.
MAIN MIX/ALT 3-4
The MAIN MIX/ALT 3-4 switch routes the signal connected to STEREO AUX RETURN
2 to either main mix (not pressed) or submix (Alt 3-4, pressed).
2.3.5 Tape input / tape output
Fig. 2.10: 2-track connectors
CD/TAPE INPUT
The CD/TAPE INPUT RCA connectors are provided for connecting a 2 track
machine (e.g. DAT recorder). They can also be used as stereo line input.
Alternatively, the output signal of a second XENYX or BEHRINGER ULTRALINK
PRO MX882 can also be connected. If you connect a hi- amplier with a source
selection switch to the CD/TAPE INPUT, you can easily switch between additional
sources (e.g. cassette recorder, CD player, etc.).
CD/TAPE OUTPUT
These connectors are wired in parallel with the MAIN OUT and carry the main
mix signal (unbalanced). Connect the CD/TAPE OUTPUT to the inputs of your
recording device. The nal output level can be adjusted via the high-precision
MAIN MIX fader.
◊ If you connect a compressor or a noise gate after the 2-track
output, the faders will probably not be able to create a satisfactory
fade-out effect.
2.3.6 Level meter and monitoring
Fig. 2.11: Control room/phones section, level meter
CD/TAPE
The TAPE switch routes the signal from the TAPE IN connectors to the level meter,
the CONTROL ROOM OUT outputs and the PHONES connector this is a simple way
to check recorded signals via monitor speakers or headphones.
ALT 3-4
Similarly, the ALT 3-4 switch routes the signal from the Alt 3-4 bus to the same
path for monitoring purposes.
MAIN MIX
The MAIN MIX switch sends the main mix signal to the above-mentioned
outputs and to the level meter.
