Appendix A - Technical Specs
Type: 2-Way Near Field
LF Driver: 5 1/4" magnetically-shield mineral-filled polypropylene curved cone
with high temperature voice coil and damped rubber surround
HF Driver: 1" magnetically-shield natural Silk Dome
Frequency Response: 33Hz - 22kHz
Crossover Frequency: 2.7kHz
LF Amplifier Power: 42W
HF Amplifier Power: 33W
S/N Ratio: > 100dB below full output, 20kHz Bandwidth
Input Connectors: 1 XLR Balanced Input & 1 TRS Balanced/ Unbalanced
Input
Polarity: Positive signal at + input produces outward LF cone displacement
Input Impedance: 20K ohms balanced, 10K ohms unbalanced
Input Sensitivity: 200 mV input produces full output with Input Sensitivity
control at maximum
Protection: RF interference, output current limiting, over temperature,
turn-on/turn-off transient, subsonic filter, external main fuse
Indicator: Power ON/OFF indicator on rear panel
Power Requirements: Dual-voltage (selectable by rear-panel switch) for either
115V/~60Hz, 230V/~50Hz; powered via detachable 3-circuit line cord
Cabinet: vinyl-laminated MDF
Dimension: 250 mm (H) x 166 mm (W) x 200 mm (D)
Weight: 5.0 kg/unit (without packing)
Remarks: Above specifications are subject to change without notice
10
