Technical Specs
Studiophile SBX Specifications* :
• Type : Bass-reflex powered subwoofer
•
Woofer Driver : 8-inch mineral-filled polypropylene cone with high-temperature
voice coil and damped rubber surround
•
Frequency Response : 30Hz – 180 Hz
•
Low-Pass Filter : Butterworth –12dB/octave <325Hz, -24dB/octave > 325Hz
•
Crossover Frequency : Adjustable 50Hz - 180Hz
•
Input Sensitivity : 89dB
•
Amplifier Power : 100W @100Hz, 4 ohm, 0.1% THD
•
Dynamic Power : 120W
•
S/N Ratio : > 100dB below full output, 100Hz
•
Input Connectors : Two XLR balanced inputs; two TRS balanced/ unbalanced inputs
•
Output Connectors : Two XLR balanced outputs for satellites, one XLR
balanced output for additional subwoofer
•
Controls: Level : Phase; Subwoofer Frequency; Satellite Frequency
•
Switches : Auto on/off; Satellite high-pass output bypass
•
Input Impedance : 20k ohms balanced, 10k ohms unbalanced
•
Input Sensitivity : 150mV input produces full output with volume control
at maximum
•
Protection : Over temperature, turn-on/off transient, subsonic filter, external
mains fuse, ALC (avoid from hard clipping)
•
Indicator : Power On (green) or Stand-by/Protection (Amber)
•
Power Requirements : Dual-voltage (selectable by rear-panel switch) for
either 120V/~60Hz, 230V/~50Hz; powered via detachable 3-circuit line cord
•
Cabinet : Vinyl-laminated MDF
•
Dimension : 15.6 in. (h) x 10.63 in. (w) x 12 in. (d)
•
Shipping Weight : 36 lbs.
* Specifications subject to change without notice.
15
