Overview

Right side

On the right side of the enclosure you’ll find 4 outlets of the power supply as RCA sockets

which all are centre positive. Correct polarity for the pedal is achieved by using the right Flex.

Top

CIOKS logo has a red LED placed in the middle of the letter ‘O’. When this LED is lit the

power supply is connected to mains and operates.

The status of each isolated output is shown by a LED indicator also situated on top of the

enclosure. The function of this advanced and unique monitoring feature is described in detail

later on.

The red settings switch with five white knobs should be used to set the output voltage of each

outlet. With all knobs to the left gives you the default 9V on all five outlets.

Knob no.

Function

Knob left (lo)

Knob right (hi)

Left side

On the left side of the enclosure you’ll find the AC power input connector, which is a C6 type

according to the IEC 60320 standard also used in many laptop adapters. On the same side as

the AC mains input you’ll find the mains voltage selector switch and fuse.

Mains voltage selector switch should be used for setting the correct mains voltage range. The

115V setting gives you 110-120V operating range and the 230V setting 220-240V range.

The fuse is the only part which may be replaced by the user. In case it’s blown, replace with a

5x20mm, T 315mA (slow blow/time lag) type.

Getting started

First make sure that the voltage value chosen on the voltage selector switch matches the mains

voltage in your wall socket. Connect the mains power cord to the power supply and mains.

Using the right Flex cable types connect your pedals to the outlets of power supply making

sure that the voltage and current is correct for every pedal.

Advanced LED Monitoring feature

Each isolated outlet has its individual LED status indicator. The indicator is fully lit in normal

All indicators take into account the actual level of mains voltage when monitoring a possible

overload. The current limits for each outlet or section of the power supply are specified at

nominal level of the mains voltage. In Europe it’s 230V and 120V in e.g. United States. If the

mains voltage is higher than nominal, you can draw more current from the power supply than

stated in the specifications. This would never be a problem. A more common situation though,

is when the mains voltage is lower than nominal. In such a case maximum current ratings for

each outlet or section might be diminished.

The advanced LED monitoring of each isolated outlet will alert you in case of an overload or

short circuit. If such a situation happens you know where to look to solve the problem.

A glance at the LED status indicators and you have proof of 100% clean power to your pedals.

Included accessories

Flex cables

CIOKS offers a great selection of different Flex cable types for connection your pedals to the

power supply. Below you see a list of the included Flex cables with your unit:

• Type 1 – Split Flex (to power two pedals of one outlet) x1

Mounting hardware

We’ve included all the needed hardware to mount the power supply on top or underneath a

Pedaltrain or Temple Audio pedalboard. You can of course also attach it to boards of other

brands. Look on CIOKS web site for more information and mounting guides.
