American DJ® - www.americandj.com - Saturn Tri LED™ Instruction Manual Page 13 American DJ® - www.americandj.com - Saturn Tri LED™ Instruction Manual Page 14
Saturn Tri LED™ Operation
trol different functions including blackout.
Manual Mode:
1. Tap the MENU button until “NANU” is displayed, and press
ENTER.
2. Using the either the UP or DOWN buttons, nd your desired color
or select color scroll. See page 10 for more details.
3. Press ENTER to conrm.
4. The optional UC3 Controller (not included) may be used to con-
trol different functions including blackout.
Master-Slave Operation (Sound Active): This function will allow
you to link up to 16 units together and operate without a controller. The
units will be sound activated. In Master-Slave operation one unit will
act as the controlling unit and the others will react to the controlling
units programs. Any unit can act as a Master or as a Slave.
1. Using standard XLR microphone cables, daisy chain your units
together via the XLR connector on the rear of the units. Remem-
ber the Male XLR connector is the input and the Female XLR
connector is the output. The rst unit in the chain (master) will use
the female XLR connector only - The last unit in the chain will use
the male XLR connector only. For longer cable runs we suggest a
terminator at the last fixture.
2. On the Master unit tap the MENU button until “SLND” is dis-
played, and press ENTER. Press the UP or DOWN button until
“MAST” is displayed, and press ENTER to conrm. Now, select
your desired operating mode and set that show by pressing the
ENTER button.
3. On the slave units tap the MENU button until “SLND” is dis-
played, select your desired Slave mode and Press ENTER.
4. The slave units will now follow the Master unit.
5. The optional UC3 Controller (not included) may be used to con-
trol different functions including blackout.
Saturn Tri LED™ 3 Channel DMX Traits
Channel Value Function
1 0 - 255 RED
0% - 100%
2 0 - 255 GREEN
0% - 100%
3 0 - 255 BLUE
0% - 100%
4 DIMMMER/STROBE
0 - 7 CLOSED
8 - 190 DIMMING 0% - 100%
191 - 200 SOUND ACTIVE
201 - 247 STROBING SLOW - FAST
248 - 255 OPEN
Channel Value Function
1 0 - 255 RED
0% - 100%
2 0 - 255 GREEN
0% - 100%
3 0 - 255 BLUE
0% - 100%
Saturn Tri LED™ 4 Channel DMX Traits
