Page - 10 Operator Manual – TRA Series Amplifiers
Copyright© 2013 – Ashly Audio Inc.
Spec Table
TRA-2075 TRA-4075 TRA-2150 TRA-4150
Power Output Per Channel
8 ohms, 80 Hz - 20 kHz, 1% THD 40 W 40 W 80 W 40 W
4 ohms, 80 Hz - 20 kHz, 1% THD 75 W 75 W 150 W 150 W
25V/70V/100V CV, 80 Hz - 20 kHz, 1% THD 75 W 75 W 150 W 150 W
Line Current Draw (all channels driven @4Ω)
Standby 37mA 39mA 89mA 102mA
Idle 320mA 565mA 370mA 660mA
1/8
th
Power Pink Noise 0.70A 1.25A 1.10A 1.95A
1/3 Power Sine Wave 1.23A 2.25A 2.10A 3.80A
Thermal Dissipation (all channels driven @4Ω)
Standby (BTU /hr) 13 15 14 23
Idle (BTU/hr) 61 113 72 137
1/8
th
Power Pink Noise (BTU/hr) 73 145 111 211
1/3 Power Sine Wave (BTU/hr) 85 150 126 263
Signal to Noise (20 Hz-20 kHz, unweighted):
>100 dB >100 dB >103 dB >103 dB
Voltage Gain: 26 dB, 36 dB sensitivity (selectable)
Output Circuitry: Class D Class D Class D Class D
Frequency Response 80 Hz - 20 kHz –3dB +/- 1.0 dB (due to internal 80 Hz HPF)
Distortion (SMPTE, typical) < 0.5% - 8Ω load, 10dB below rated power
Distortion (THD-N, typical) < 0.5% - 8Ω load, 10dB below rated power, 20Hz-20kHz
Damping Factor - 8 ohm load, < 1 kHz > 200 into 8Ω
Input Impedance 20 kΩ, balanced
Maximum Input Level: +21 dBu
Input Impedance 20kΩ balanced
Cooling Convection
Front Panel Indicators per channel Clip & Signal
Front Panel Indicators overall power, standby, protect
Attenuators Per channel: front panel
Input Connectors, each channel 3- Pin Euroblock
Output connectors, each channel Screw terminals
Amplifier Protection Output Overcurent, DC Output, Mail Supply Rail Overvoltage
Chassis Temperature, Inrush Limiting, Mains Fuse
Power Cable Connector 3-Prong IEC
Dimensions 19” x 3.5” x 11”
Weight 19.5 lbs 29.5 lbs 19.5 lbs 29.5 lbs
All Specifications Subject to Change or Improvement Without Notice.
