Audio Parameters

FrequencyResponse 80–18kHz+/-2dB

BalancedOutput 20dBV(max@40kHzdeviation)

UnbalancedOutput Adjustable8mVto0.755VRMS

Distortion <1.0%,0.4%typical(ref1kHz,40kHzdeviation)

Signal-to-NoiseRatio >100dBAWeighted

DynamicRange >95dB

Transmitters BP-300 and HT-300

RadiatedOutput 8mWtypical

MicrophoneHeadElectroVoice PL22Dynamic

PowerRequirements TwoAABatteries

StandardLavalierMicrophone

EVULM18 

Uni-DirectionalCondenser

TA4FConnectorWiring Pin1:Ground;Pin2MicInput;Pin3:+5Vbias;Pin4:N/C

PowerRequirements TwoAABatteries

BatteryLife(Typical) >14hourswithAAAlkalineTypical

BodypackAntenna Flexibleexternal¼wave

HandheldAntenna InternalProprietary

Dimensions(Handheld) 26.7cm(10.57in.)Long

Dimensions(Bodypack)

3.3in.Hx2.6in.Wx0.89in.D

84mmHx66mmWx23mmD
