DETAILED coMponent descriptions

2.1 | Receiver Setup & Operation

1.Placethereceiverandantennaswherethereisaclearlineofsighttotheareawherethetransmitter

willbeused.Rotatetheantennastoseparatethemby90degrees.

2. Install the appropriate power connection blades into the power supply and connect the

power supplycordtothereceiver.PlugthepowersupplyintoanACoutlet.Pushthepower

buttontoturnthereceiveronandconrmthatitisonbycheckingthemaindisplayscreen.

3. Manual Channel Change

  a.The and buttonsallowyoutoscrollthroughtheChannels.WhentheChannel

youdesireisdisplayed,stopscrolling.

  b.After2secondsthedisplayedchannelnumberwillstarttoash.

  c.Thenumberwillstopashingandthenewchannelisinstalled.

  d.TurnonthetransmitterandholdtheEZsyncportfacingthereceiverEZSyncport,

aboutafoot(50cm)away.

ANTENNA B ANTENNA A12V .500mA

MIN MAX

VOLUME

LEVEL

-10dB 0dB

BALANCED OUT UNBALANCED OUT
