Lincoln Navigator (2001) [165/256] Roadside emergencies
![Lincoln Navigator (2001) [165/256] Roadside emergencies](/views2/2009920/page165/bga5.png)
The high-current fuses are coded as follows:
Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box Description
1 20A * Power Point
2 30A* Powertrain Control Module
3 30A* Headlamps/Autolamps
4 20A* Console Powerpoint
5 20A* Trailer Tow Backup/Park Lamps
6 15A* Parklamps/Autolamps, Feeds Passenger
Compartment Fuse 18
7 20A* Horn
8 30A* Power Door Locks
9 15A* Daytime Running Lamps (DRL), Fog Lamps
10 20A* Fuel Pump
11 20A* Alternator Field
12 10A* Rear Wipers
13 15A* A/C Clutch
14 — Not Used
15 10A* Running Board Lamps
16 — Not Used
17 10A* Delayed Accessory (Audio, Flip Windows)
18 15A* Powertrain Control Module, Fuel Injectors,
Fuel Pump, Mass Air Flow Sensor
19 10A* Trailer Tow Stop and Right Turn Lamp
20 10A* Trailer Tow Stop and Left Turn Lamp
21 — Not Used
22 — Not Used
23 15A* HEGO Sensors, Canister Vent,
Transmission, CMS Sensor
24 — Not Used
101 30A** Trailer Tow Battery Charge
102 50A** Four Wheel Antilock Brake Module
103 50A** Junction Box Battery Feed
