Compact High Power

Single 12" Subwoofer

Key Features:

䉴

2263H 12" Differential Drive

dual

voice coil dual gap, neodymium

magnet transducer

䉴

1000 watts continuous pink noise,

4000 watts peak power handling

capacity

䉴

Large vent area for high output with

low distortion

䉴

For ground-stacked or suspended

applications in stand-alone arrays or in

combination with other AE Series

products

Applications:

䉴

Performing Arts Facilities

䉴

Theatrical Sound Design

䉴

Auditoriums

䉴

Worship Facilities

䉴

Live Clubs

䉴

Dance Clubs

䉴

Sports Facilities

䉴

Themed Entertainment Venues

The ASB6112 is a high power,

lightweight front-loaded vented

subwoofer enclosure housing JBL’s

2263H Differential Drive

dual coil dual

gap 12" woofer. This woofer features

neodymium magnet and ultra robust

cone for extra long life.

The enclosure is constructed of

multiply hardwood coated in JBL’s

rugged DuraFlex™ ﬁnish and is heavily

braced to maximize low-frequency

performance. The rectangular enclosure

is ﬁtted with sixteen M10 threaded

attachment points and utilizes a

14-gauge steel grille internally lined

with acoustically transparent foam to

provide additional driver protection and

give a very professional appearance.

The ASB6112 is part of JBL’s AE

Series, a versatile family of

loudspeakers intended for a wide

variety of applications.

Speciﬁcations:

System:

Frequency Range (-10 dB): 35 Hz – 1 kHz

Frequency Response (± 3 dB): 43 Hz – 1 kHz

Transducer Power Rating

: 1000 W (4000 W peak), 2 hrs.

Long-Term System Power Rating

: 700 W (2800 W peak), 100 hrs.

Maximum SPL (1m)

: 40 Hz - 300 Hz: 126 dB-SPL cont avg (132 dB peak)

System Sensitivity

: 40 Hz - 300 Hz: 96 dB-SPL, 1W (2.83V) @ 1m

Nominal Impedance: 8 ohms

Transducers:

Low Frequency Driver: 1 x 2263H, 305 mm (12 in) dia., 75 mm (3 in) Dual Coil Dual

Gap neodymium Differential Drive

driver

Physical:

Enclosure: Rectangular cabinet, 16 mm (5/8 in) exterior grade 11-ply birch

plywood

Suspension Attachment: 16 points (4 top, 4 bottom, 4 each side), M10 threaded hardware

Finish: Black DuraFlex™ ﬁnish. White available upon request.

Grille: Powder coated 14 gauge perforated steel, with acoustically

transparent black foam backing.

Input Connector: NL4 Neutrik Speakon

and CE-compliant covered barrier strip

terminals. Barrier terminals accept up to 5.2 sq mm (10 AWG)

wire or max width 9 mm (.375 in) spade lugs. Speakon in

parallel with barrier strip for loop-through.

Environmental Speciﬁcations: Mil-Std 810; IP-x3 per IEC529.

Dimensions (H x W x D in 406 x 369 x 483 mm

vertical cabinet orientation): (16.0 x 14.5 x 19.0 in)

Net Weight: 16.3 kg (36.0 lb)

Optional Accessories: M10 x 35 mm forged shoulder eyebolts with washers.

AES standard, one decade pink noise with 6 dB crest factor within device's operational band, free air. Standard AES 2 hr rating

plus long-term 100 hr rating are speciﬁed for low-frequency transducers.

AES standard, one decade pink noise with 6 dB crest factor, in cabinet, long-term 100 hr rating.

Calculated based on power rating and sensitivity, exclusive of power compression.

Half-space (2␲) loading, averaged in speciﬁed frequency band.

JBL continually engages in research related to product improvement. Changes introduced into existing products without notice

are an expression of that philosophy.
