Dell Vostro 3670 3670-6665 [20/31] Option description

Option Description

• Enabled

• Enabled w/PXE: This option is enabled by default.

SATA Operation Allows you to congure the internal SATA hard-drive controller. The options are:

• Disabled

• AHCI

• RAID On(default)

Drives Allows you to congure the SATA drives on board. All drives are enabled by default. The options are:

• SATA-0

• SATA-1

• SATA-2

• SATA-3

• M.2 PCIe SSD-0

SMART Reporting This eld controls whether hard drive errors for integrated drives are reported during system startup. This

technology is part of the SMART (Self-Monitoring Analysis and Reporting Technology) specication. This option is

disabled by default.

• Enable SMART Reporting

USB Conguration This eld congures the integrated USB controller. If Boot Support is enabled, the system is allowed to boot any

type of USB Mass Storage Devices (HDD, memory key, oppy).

If USB port is enabled, device attached to this port is enabled and available for OS.

If USB port is disabled, the OS cannot see any device attached to this port.

• Enable USB Boot Support (default)

• Enable Front USB Ports(default)

• Enable Rear USB Ports (default)

NOTE: USB keyboard and mouse always work in the BIOS setup irrespective of these settings.

Front USB

Conguration

This eld enables or disables the front USB conguration

• Front Port 1 (Bottom Right)* (default)

• Front Port 2 (Bottom Left)* (default)

* denotes a USB 3.0-capable port

Rear USB

Conguration

This eld enables or disables the front USB conguration

• Rear Port 1

• Rear Port 2

• Rear Port 3 (w/RJ-45)

• Rear Port 4 (w/RJ-45)

* denotes a USB 3.0-capable port

Audio This eld enables or disables the integrated audio controller. By default, the Enable Audio option is selected.

20 System setup
