Hyundai Home Assistant TX DEH1 [6/36] Appliance control

Electric dehumidier for changing

humidity level

5. APPLIANCE CONTROL

Fig. 3

6 5

When you push the button to change operation modes, the unit will make a beep sound to indicate

that it is changing modes

1. Power pad Press to turn the dehumidier on and o

2. Mode pad

Press to select the desired operation mode from Dehumidifying, Dryer, Continuous dehumidifying

and Smart dehumidifying

Note: Dryer and Smart dehumidifying modes are optional

3 and 4. Down/Up Pads

- Humidity Set Control Pads

The humidity level can be set within a range of 35% RH(relative humidity) to 85% RH(relative

humidity)

For drier air, press the “-” pad and set to lower percent value (%)

For damper air, press the “+” pad and set a higher percent value (%)

- Timer Set Control Pads

Use the up/down pads to set the Auto start and Auto stop time from 0.0 to 24.

5. Timer pad

Press to initiate the Auto start and Auto stop feature, in conjuction with the “+” and “-” key pads

6. Turbo pad

Control the fan speed. Press to select either high or normal fan speed. Set the fan control to high

for maximum moisture removal. When the humidity has been reduced and quiet operation is

preferred, set the fan control to normal

7. Display

Shows the set % humidity level from 35% to 85% or auto start/stop time(0~24) while setting,

then shows the actual room % humidity level in a range of 30%RH to 90%RH
