Maximum Impact

Horn-Loaded Subwoofer

Key Features:



1 x 18" 2242H SVG™ Driver.



Designed to be used singly or in

multiples (2 minimum, 4 optimum)

with proximity placement or with

proper boundary surface loading.



Maximum low frequency output &

sensitivity.



Excellent “punch” with true sub-bass

extension.

Applications:



Performing arts facilities



Theatrical sound design



Auditoriums



Houses of worship



Live clubs



Dance-clubs/discotheques



Sport facilities



Themed entertainment venues

ASH6118 is a high power horn-

loaded subwoofer system comprised of

one 460 mm (18 in) SVG Super Vented

Gap low frequency driver. The slow-

expansion internal folded horn

provides maximum sensitivity, output

level and subwoofer impact.

ASH6118 is part of JBL’s AE

Application Engineered Series, a

versatile family of loudspeakers for a

wide variety of applications.

Speciﬁcations:

System:

Frequency Range (-10 dB): 1 cabinet: 25 Hz – 250 Hz

2 cabinets: 24 Hz – 250 Hz

4 cabinets: 22 Hz – 250 Hz

Frequency Response (±3 dB): 1 cabinet: 30 Hz – 200 Hz

2 cabinets: 28 Hz – 200 Hz

4 cabinets: 26 Hz – 200 Hz

Transducer Power Rating (AES)

:1 cabinet: 1200 W (4800 W peak), 2 hrs, 800 W (3200 W peak),

100 hrs

2 cabinets: 2400 W (9600 W peak), 2 hrs, 1600 W (6400 W

peak), 100 hrs

4 cabinets: 4800 W (19200 W peak), 2 hrs, 3200 W (12800 W

peak), 100 hrs

Long-Term System Power Rating

:1 cabinet: 800 W (3200 W peak), 100 hrs

2 cabinets: 1600 W (6400 W peak), 100 hrs

4 cabinets: 3200 W (12800 W peak), 100 hrs

Maximum SPL

: 30 Hz – 140 Hz:

1 cabinet: 133 dB-SPL cont avg (139 dB peak)

2 cabinets: 138 dB-SPL cont avg (144 dB peak)

4 cabinets: 144 dB-SPL cont avg (150 dB peak)

System Sensitivity (dB-SPL, 1W @ 1m)

: 30 Hz – 150 Hz:

1 cabinet: 102 dB

2 cabinets: 104 dB

4 cabinets: 107 dB

Nominal Impedance: 8 ohms per cabinet

Transducers:

Low Fr

equency Driver: Per cabinet: 1 x JBL 2242H 460 mm (18 in) SVG™ driver with

100 mm (4 in) voice coil

Physical:

Enclosure: Rectangular cabinet, 18 mm (3/4 in) exterior grade 13-ply birch

plywood

Suspension Attachment: None

Finish: Black DuraFlex™ ﬁnish. White available upon request.

Input Connector: NL4 Neutrik Speakon

and CE-compliant covered barrier strip

terminals. Barrier terminals accept up to 5.2 sq mm (10 AWG)

wire or max width 9 mm (.375 in) spade lugs. Speakon in paral-

lel with barrier strip for loop-through.

Environmental Speciﬁcations: Mil-Std 810; IP-x3 per IEC529.

Dimensions (H x W x D in 564 x 1530 x 1288 mm

horizontal cabinet orientation): (22.3 x 56.4 x 50.7 in)

Net Weight: 159.3 kg (351 lb)

AES standard, one decade pink noise with 6 dB crest factor within device's operational band, free air. Standard AES 2 hr rating

plus long-term 100 hr rating are speciﬁed for low-frequency transducers.

AES standard, one decade pink noise with 6 dB crest factor, in cabinet, long-term 100 hr rating.

Calculated based on power rating and sensitivity, exclusive of power compression.

Half-space (2) loading, averaged in speciﬁed frequency band.

JBL continually engages in research related to product improvement. Changes introduced into existing products without notice

are an expression of that philosophy.
