![Lincoln Blackwood (2002) [153/240] Roadside emergencies](/views2/2010827/page153/bg99.png)
Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box Description
10 20A* Fuel pump
11 20A* Alternator field
12 20A* Rear auxiliary power point
13 15A* A/C clutch
14 20A* Box power point
15 – Not used
16 — Not used
17 10A* Delayed accessory
18
15A*
PCM, Fuel injectors, Fuel pump relay,
Idle Air control, Mass air flow sensor
19 10A* Trailer tow stop and right turn lamp
20 10A* Trailer tow stop and left turn lamp
21 — Not used
22 — Not used
23
15A*
HEGO sensor, Canister vent, Automatic
transmission, CMS sensor
24 — Not used
101 30A** Trailer tow battery charge
102
50A**
Anti-lock Brake System (ABS) module,
Traction control
103 50A** Junction block battery feed
104 — Not used
105 40A** Climate control front blower
106 — Not used
107 30A** Passenger power seat
108 30A** Trailer tow electric brake
109 50A** Air suspension
110 30A** Climate control seats
111
40A**
Ignition switch battery feed (start and
run circuits)
112 30A** Drivers power seat, Adjustable pedals
Roadside emergencies
153
