Lincoln LS (2001) [246/272] Capacities and specifications
![Lincoln LS (2001) [246/272] Capacities and specifications](/views2/2010830/page246/bgf6.png)
MOTORCRAFT PART NUMBERS
Component 3.0L-4V V6 engine 3.9L-4V V8 engine
Air filter element FA-1679 FA-1679
Fuel filter FG-986 FG-986
Battery (standard) BXT-66-650 BXT-66-650
Battery (optional) BXT-66-750 BXT-66-750
Oil filter FL-400S FL-2008
PCV valve EV-243 N/A
Spark plugs* AGSF-32FS AGSP-32F
* Refer to Vehicle Emissions Control Information (VECI) decal for spark
plug information.
REFILL CAPACITIES
Fluid Ford Part Name Application Capacity
Brake fluid and
clutch fluid (if
equipped)
High Performance
DOT 3 Motor Vehicle
Brake Fluid
1
All Fill to MAX
line on
reservoir
Engine oil
(includes filter
change)
Motorcraft SAE
5W-20 Super
Premium Motor Oil
3.0L-4V V6
engine
6.5L
(6.9 quarts)
Motorcraft SAE
5W-30 Super
Premium Motor Oil
3.9L-4V V8
engine
5.7L
(6.0 quarts)
Engine
coolant
2
Premium Engine
Coolant
3.0L-4V V6
engine
10.6L
(11.2 quarts)
3.9L-4V V8
engine
11.3L
(11.9 quarts)
Power steering
fluid
Motorcraft
MERCONt ATF
All Fill to MAX
line on
reservoir
Engine cooling
fan fluid
Motorcraft
MERCONt ATF
All Fill to MAX
line on
reservoir
Capacities and specifications
246
