DDE ST6562L деталировка [29/34] Fuel tank

零零零零零零零

零零零零零

Description

No. Part No.

LC168F(D)-I LC168F(D)-II G160F(D) G200F(D)

1 E40211-T000010

当当当当

CLIP , TUBE 2 2 2 2

2 801600-144000

注注注

JOINT ASSY. , FUEL TANK 1 1 1 1

3 801000-144000

当当

TANK COMP ., FUEL 1 1 - -

4 804000-144000 当当当

CAP COMP ., FUEL FILLER 1 1 1 1

5 804001-144000 当当当当当当

PACKING , FUEL FILLER CAP 1 1 1 1

6 E40201-144000 注注注注

FILTER , FUEL 1 1 1 1

7 SB0625-0000000DL

BOLT , FLANGE , 6×25 1 1 1 1

8 801602-144000 注注注注注注

PACKING , JOINT 1 1 1 1

9 M80600-0000000DL

NUT , FLANGE , 6MM 2 2 2 2

10 801086-144000

TUBE , FUEL 1 1 1 1

11 804000-144000 当当当

CAP,FUEL FILLER 1 1 - -

12 801000-102000 当当

TANK COMP ., FUEL - - 1 1

13 801600-144000 注注注

JOINT , FUEL TANK 1 1 1 1

气气气气FUEL TANK气

零零 (Reqd. QTY)

零零零零零零零M6×25

零零零零零M6

零零4×8×170
