Near-Ultrasound audio is the 18.5 kHz to 20 kHz band.
Device implementations:
MUST correctly report the support of near-ultrasound audio capability via the
AudioManager.getProperty API as follows:
If PROPERTY_SUPPORT_MIC_NEAR_ULTRASOUND is "true", the following requirements MUST be met
by the VOICE_RECOGNITION and UNPROCESSED audio sources:
[C-1-1] The microphone's mean power response in the 18.5 kHz to 20 kHz band MUST be
no more than 15 dB below the response at 2 kHz.
[C-1-2] The microphone's unweighted signal to noise ratio over 18.5 kHz to 20 kHz for a
19 kHz tone at -26 dBFS MUST be no lower than 50 dB.
If PROPERTY_SUPPORT_SPEAKER_NEAR_ULTRASOUND is "true":
[C-2-1] The speaker's mean response in 18.5 kHz - 20 kHz MUST be no lower than 40 dB
below the response at 2 kHz.
7.9. Virtual Reality
Android includes APIs and facilities to build "Virtual Reality" (VR) applications including high quality
mobile VR experiences. Device implementations MUST properly implement these APIs and
behaviors, as detailed in this section.
7.9.1. Virtual Reality Mode
Android includes support for VR Mode , a feature which handles stereoscopic rendering of
notifications and disables monocular system UI components while a VR application has user focus.
7.9.2. Virtual Reality Mode - High Performance
If device implementations support VR mode, they:
[C-1-1] MUST have at least 2 physical cores.
[C-1-2] MUST declare the android.hardware.vr.high_performance feature.
[C-1-3] MUST support sustained performance mode.
[C-1-4] MUST support OpenGL ES 3.2.
[C-1-5] MUST support android.hardware.vulkan.level 0.
SHOULD support android.hardware.vulkan.level 1 or higher.
[C-1-6] MUST implement EGL_KHR_mutable_render_buffer ,
EGL_ANDROID_front_buffer_auto_refresh , EGL_ANDROID_get_native_client_buffer ,
EGL_KHR_fence_sync , EGL_KHR_wait_sync , EGL_IMG_context_priority , EGL_EXT_protected_content
, EGL_EXT_image_gl_colorspace , and expose the extensions in the list of available EGL
extensions.
[C-1-8] MUST implement GL_EXT_multisampled_render_to_texture2 , GL_OVR_multiview ,
GL_OVR_multiview2 , GL_OVR_multiview_multisampled_render_to_texture , GL_EXT_protected_textures
, GL_EXT_EGL_image_array , GL_EXT_external_buffer , and expose the extensions in the list of
available GL extensions.
[C-1-24] MUST implement VK_KHR_shared_presentable_image , VK_GOOGLE_display_timing and
expose the extensions in the list of available Vulkan extensions.
Page 110 of 132
